500W UPS Power Inverter

Category

500W Pure Sine Wave Inverter with Battery Charger

Additional information

Model NO.

HPC500
Rated Power

500W
Peak Power

1000W
Shell Material

Aluminum
Dimension

310*150*70mm (L*W*H)
Net Weight

2.50KG
ask for quote

Product Details:

  • Inverter part: Input voltage DC 12V/24V/48V
  • Inverter part: Output voltage AC 110V/230V
  • Charger part: Input voltage AC 90~120V/190-265V
  • Charger part: Output voltage DC 12V/24V/48V
  • Max current: 10A/5A/2.5A
  • Transfer time:＜10ms
  • Frequency: 50/60HZ
  • No-load current draws:＜0.40A
  • Output Waveform: Pure sine wave
  • USB Port: 5V, 2.1A
  • Protection function: Battery Low voltage, over-temperature, over-voltage, short circuit, reverse polarity, overload protection.
  • Cooling way: Cooling fan by load and temperature control
  • Certification: CE-EMC/LVD, RoHS



     Packing details:

  • Poly bag+EPE+inner box+carton
  • 1PCS/Inner CTN, 4PCS/Master CTN
  • CTN N.W.: 10.00 KGS
  • CTN G.W.: 13.00 KGS
  • CTN Meas: 45*46*33cm
